IP67 Cable Grommet 1.0 mm 4.0 mm EPDM
This liquid tight grommet is manufactured from grey EPDM and is rated to IP67 when installed on your electrical enclosures. Made to fit PG threads.
Essentra part number
10314227
Maximum Cable Bundle Diameter
20.0mm
Colour
Grey
Minimum Cable Bundle Diameter
14.0mm
Maximum Panel Thickness
4.0mm
Minimum Panel Thickness
1.0mm
Height Under Flange
18.3mm
Overall Height
24.4mm
Thread Size
PG-21
Material
EPDM
Mounting Hole Diameter
29.0mm
Flange Thickness
6.1mm
Type
2
